Seal your hose properly — sized automatically to match the bore you selected. We’ve added 2 — one for each end of the hose. Adjust if you need more or fewer.
The Master Clip Vinyl Red is a suction & blower hose made from PVC foil/film. It is very flexible and light in weight, moderately pressure resistant, with a grey wall.
Constructed as a spiral hose with clamping profile with a pvc film wall, it operates from -20 °C to +70 °C (peaks to 80 °C). Available in bore sizes from 152–406 mm, in 6 m, 10 m, 15 m lengths.
| Construction & material | |
|---|---|
| Type of construction | spiral hose with clamping profile |
| Design of the helix | metal band, formed as a clamping profile |
| Material of the helix | steel strip, hot-dip galvanised |
| Design of the external spiral | designed as an additional protective profile |
| Execution of the wall | made of pure material, single layer executed |
| Material of the wall | PVC film |
| Properties | |
| Chemical Properties | silicone-free |
| Mechanical Properties | compressible approx. 1:6 |
| Flexibility | very flexible |
| Weight | light |
| Pressure Resistance | moderately pressure resistant |
| Colour | grey |
| Operating temperature | |
| Temperature Range | -20 to 70 °C |
| short-term maximum temperature | peaks to 80 °C |
Plant & Mechanical Engineering, Ventilation & Air-conditioning, Chemistry, Plastics.
← swipe to see all columns →
| Bore DN (mm) | Outer Ø (mm) | Bend radius (mm) | Wall (mm) | Op. pressure (bar) | Vacuum (bar) |
|---|---|---|---|---|---|
| 152 | — | 90.0 | — | 0.14 | 0.04 |
| 203 | — | 120.0 | — | 0.1 | 0.03 |
| 254 | — | 175.0 | — | 0.08 | 0.02 |
| 305 | — | 210.0 | — | 0.06 | 0.01 |
| 406 | — | 280.0 | — | 0.03 | 0.01 |
